Item | Parameter | |||||
Pixel Pitch | PH 2 | PH 2.5 | PH 3 | PH 4 | PH 5 | PH 6 |
LED Model | SMD2121 black | SMD1515 black |
SMD2121 black |
SMD2121 black |
SMD3528 white | SMD3528 white |
Module Size | 128 x 128 | 160 x 160 | 192 x 96 | 256 x 128 | 320 x 160 | 192 x 192 |
Resolution | 64 x 64 | 64 x 64 | 64 x 32 | 64 x 32 | 64 x 32 | 32 x 32 |
Physical Pixel Density | 250000 pixel/sqm |
160000 pixel/sqm |
111111 pixel/sqm |
62500 pixel/sqm |
40000 pixel/sqm |
27777 pixel/sqm |
Scan Mode | 32 scan | 32 scan | 16 scan | 16 scan | 16 scan | 8 scan |
Brightness | >2500cd/sqm | >2500cd/sqm | >2000cd/sqm | >2000cd/sqm | >2000cd/sqm | >2000cd/sqm |
Optimal Viewing Distance | >2m | >2m | >3m | >4m | >5m | >6m |
Weight | 0.18kg/pcs | 0.20kg/pcs | 0.16kg/pcs | 0.22kg/pcs | 0.40kg/pcs | 0.28kg/pcs |
Indoor LED Display Panel
LED Display Panel is a flat panel display, which uses an array of light-emitting diodes as pixels for a video display. Our normal indoor display products include many types and cabinet sizes
which can satisfy different indoor occasions.
- The use of high quality LED chip achieves good flatness, high anti-static-electricity capacity
- The well structured PCB and the evenly-distributed current ensure low heat generation
- High contrast ratio and refresh rate
- Perfect gray scale under 30% brightness
- Low attenuation of LED, good consistency and uniformity of brightness and colour
- Low power consumption and energy-saving
Information
Item | Module Size (mm) | Resolution (pixel) | Single Module Electric Current (A) | Max Power Consumption (sqm) |
PH 2 | 128 x 128 | 4096 | 4 – 4.5 | 1200w |
PH 2.5 | 160 x 160 | 4096 | 4 – 4.5 | 1200w |
PH 3 | 192 x 96 | 2048 | 4.3 – 4.7 | 1000w |
PH 4 | 256 x 128 | 2048 | 4.3 – 4.7 | 1000w |
PH 5 | 320 x 160 | 2048 | 4.3 – 4.7 | 1000w |
PH 6 | 192 x 192 | 1024 | 2.3 – 2.5 | 800w |
-
Transit Hub
LED displays are widely applied to display real-time traffic info in airport, train station, bus station, subway station and ferry terminal.
-
Vocal Concert
LED displays are necessary products for a successful,Magnificent and charming vocal concert.
-
Stock Exchange Centre
LED displays has become the necessary product to display real-time trading information
-
Supermarket and Mall
LED displays has become an indispensable tool for merchants to distribute promotion advertisements.
-
Commercial Event
In nowadays business world, LED displays are ubiquitous in such occasions as shopping centre, exhibition centre, supermarkets, cinema and hotels.
